API#

The complete public API is auto-generated from docstrings by sphinx-autoapi. The package is pure Python with a single runtime dependency: NumPy.

Foundation

Core constants, rotation mathematics, and display formatting.

constants · rotation · display

constants
Geometry Primitives

Axis parsing and individual rotation stages.

axes · stage

stage
Crystallography

Lattice, reflections, sample, and radiation source.

lattice · reflection · sample · radiation

lattice
Diffractometer

Geometry class, diffraction modes, and predefined geometry factories.

diffractometer · mode · factories

diffractometer
Calculations

Orientation, forward problem, Q/energy conversions, trajectories, surface diffraction, and lattice refinement.

orientation · forward · conversions · surface · scan · refinement

orientation
Full Module Index

Every public module, class, function, and constant, auto-generated from source docstrings.

ad_hoc_diffractometer

Module Dependency Graph#

The diagram below shows how the source modules depend on each other. Arrows point from a module to the modules it imports. Modules are grouped by layer.

digraph deps { graph [rankdir=TB, fontname="sans-serif", fontsize=11, bgcolor="transparent", splines=ortho, nodesep=0.4, ranksep=0.6] node [shape=box, style="rounded,filled", fontname="sans-serif", fontsize=10, margin="0.15,0.08"] edge [color="#555555", arrowsize=0.7] // ── Foundation (grey) ────────────────────────────────── subgraph cluster_foundation { label="Foundation" style=filled fillcolor="#f0f0f0" color="#aaaaaa" fontname="sans-serif" fontsize=11 constants [label="constants" fillcolor="#e0e0e0"] rotation [label="rotation" fillcolor="#e0e0e0"] display [label="display" fillcolor="#e0e0e0"] } // ── Geometry primitives (blue) ────────────────────────── subgraph cluster_primitives { label="Geometry Primitives" style=filled fillcolor="#ddeeff" color="#6699cc" fontname="sans-serif" fontsize=11 axes [label="axes" fillcolor="#c8dff8"] stage [label="stage" fillcolor="#c8dff8"] } // ── Crystallography (green) ───────────────────────────── subgraph cluster_crystal { label="Crystallography" style=filled fillcolor="#ddf0dd" color="#66aa66" fontname="sans-serif" fontsize=11 lattice [label="lattice" fillcolor="#c0e8c0"] reflection [label="reflection" fillcolor="#c0e8c0"] sample [label="sample" fillcolor="#c0e8c0"] radiation [label="radiation" fillcolor="#c0e8c0"] } // ── Diffractometer (amber) ────────────────────────────── subgraph cluster_diffractometer { label="Diffractometer" style=filled fillcolor="#fff3cc" color="#ccaa00" fontname="sans-serif" fontsize=11 mode [label="mode" fillcolor="#ffe999"] diffractometer [label="diffractometer" fillcolor="#ffe999"] factories [label="factories" fillcolor="#ffe999"] } // ── Calculations (orange) ─────────────────────────────── subgraph cluster_calculations { label="Calculations" style=filled fillcolor="#ffe8d6" color="#cc7733" fontname="sans-serif" fontsize=11 orientation [label="orientation" fillcolor="#ffd0b0"] forward [label="forward" fillcolor="#ffd0b0"] conversions [label="conversions" fillcolor="#ffd0b0"] surface [label="surface" fillcolor="#ffd0b0"] scan [label="scan" fillcolor="#ffd0b0"] refinement [label="refinement" fillcolor="#ffd0b0"] } // ── Edges ─────────────────────────────────────────────── // Foundation axes -> constants stage -> rotation // Crystallography lattice -> display reflection -> display sample -> lattice sample -> reflection // Diffractometer diffractometer -> axes [style=dashed] diffractometer -> constants diffractometer -> display [style=dashed] diffractometer -> forward [style=dashed] diffractometer -> lattice [style=dashed] diffractometer -> mode [style=dashed] diffractometer -> orientation [style=dashed] diffractometer -> radiation [style=dashed] diffractometer -> reflection diffractometer -> rotation [style=dashed] diffractometer -> sample [style=dashed] diffractometer -> stage [style=dashed] diffractometer -> surface [style=dashed] factories -> axes factories -> constants factories -> diffractometer factories -> mode factories -> stage // Calculations orientation -> reflection orientation -> rotation orientation -> stage forward -> display [style=dashed] forward -> diffractometer [style=dashed] forward -> mode forward -> orientation conversions -> sample surface -> diffractometer [style=dashed] scan -> diffractometer [style=dashed] scan -> rotation refinement -> lattice refinement -> orientation refinement -> reflection refinement -> rotation }

ad_hoc_diffractometer module dependencies#

Note

Dashed arrows indicate that the import is deferred (inside a function body or guarded by TYPE_CHECKING) to avoid circular imports.

Full Module Reference#
